KK Aluminum is a raw material manufacturer of aluminum foil rolls (it only provides aluminum foil base materials instead of the later composite, etching, curing and other processing technologies).
Transformer is composed of winding, core, oil tank and insulation sleeve four parts. Its main parts are the winding and the core (body), the winding is the transformer circuit, the core is the magnetic circuit of the transformer. The two form the core of the transformer - the electromagnetic part. Transformer aluminum foil strip is the most important material for making transformer windings, which directly affects the quality of transformer.
Transformer aluminum foil and strip are generally selected 1060 aluminum strip, which contains more than 99.6% aluminum and is also known as pure aluminum plate. It belongs to a commonly used series in the aluminum plate and strip family. The advantages of this series of aluminum plate: for the commonly used series, the production process is relatively single, the technology is relatively mature, the price compared with other high-grade alloy aluminum plate has a huge advantage. Transformer aluminum foil selection of industrial pure aluminum, with high plasticity, corrosion resistance, electrical conductivity and thermal conductivity, easy to withstand a variety of pressure processing and extension, bending.
Materials: 1060-O, 1050, 1050A, 1070, 1070A, etc
Application: Dry type transformer aluminum foil, transformer aluminum belt
Thickness: 0.2mm--3.0mm, width: 20mm-1650mm.
Description: Smooth surface, no scratches. The edge can be chamfered (rounded corner, round edge), no burr, resistivity less than or equal to 0.028.
Packing: Wooden pallet/fumigation-free wooden pallet, inner diameter 300mm or 500mm. Use moisture-proof paper packing, middle paper sleeve.
